SKU: QFP-AC12DG-xxMC-FSZ
Product Highlights
Hot-pluggable QSFP- DD/QSFP28 form factor
8 channels full-duplex transceiver module
Supports data rate up to 26Gbps per channel
8 channels 850nm VCSEL array and PIN photo-detector array
Internal CDR circuits within receiver and transmitter data paths
Supports CDR bypass via I2C controlled
Low power consumption: 200GBASE-SR8 QSFP DD<4W and 100GBASE-SR4 QSFP28<2.5W
Maximum link length of 70m on OM3 MMF and 100m on OM4 MMF
Single MTP/MPO receptacle
Built-in digital diagnostic monitoring functionality
I2C management interface,Single 3.3V power supply
RoHS 2.0 compliant (lead free),Commercial case temperature of 0 to 70°C
