1.25G SFP BIDI 1000BASE 60km TX1310nm/RX1550nm Transceiver 1

1.25G SFP BIDI 1000BASE 60km TX1310nm/RX1550nm Transceiver 2

1.25G SFP BIDI 1000BASE 60km TX1310nm/RX1550nm Transceiver

SKU: SFP-BL3524-60xx

Product Highlights

Supports up to 1.25Gbps bit rates

Hot-pluggable SFP footprint

Compliant with SFP MSA and SFF-8472 with single LC receptacle

Compatible with RoHS

Single +3.3V power supply

Real Time Digital Diagnostic Monitoring

Download File

Required Products

Total price discount:

BUY TOGETHER

Inquiry together

1.25G SFP BIDI 1000BASE 60km Transceiver Single Mode 1310nm TX / 1550nm RX

The 1.25G SFP BIDI 1000BASE 60km transceivers are high performance, cost effective modules supporting data rate of 1.25Gbps and 60km transmission distance with SMF.

The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.

Technical Specification

Vendor Name	FIBERTOP	FIBERTOP Part Number(s)	SFP-BL3524-60xx
Transceiver Type	BIDI	Reach	60km
Wavelength	1310nm Tx/1550nm Rx	Form Type	SFP
Speed Description	1.25-Gigabit	Media	SMF
Connector	Simplex LC	Extinction Ratio	>9.0 dBm
TX Power	-1~-3 dBm	Receiver Sensitivity	>-23 dBm
Applications	1.25Gbps Optical systems Gigabit Ethernet 1.063Gbps Fiber Channel Other Optical links	Environment	Operating:0 to 70°C Storage: -40°C to 85°C
