FIBERTOP 40G ER4 QSFP+ SMF 1310nm 40km LC DOM Transceiver Module 1

FIBERTOP 40G ER4 QSFP+ SMF 1310nm 40km LC DOM Transceiver Module 2

FIBERTOP 40G ER4 QSFP+ SMF 1310nm 40km LC DOM Transceiver Module

SKU: QFP-CW31FG-40DC

Product Highlights

4 CWDM lanes MUX/DEMUX design

Hot-pluggable QSFP+ form factor

Transmission data rate up to 11.3Gbps per channel

Up to 40km transmission

SMF LC duplex connector

RoHS compliant

Download File

Required Products

Total price discount:

BUY TOGETHER

Inquiry together

Compatible With OEM Part Number(s)

QFP-CW31FG-20DC

Compatible OEM

FIBERTOP

Transceiver Type

LR4

Form Type

QSFP+

Speed Description

40-Gigabit

Reach

20km

Wave length

1310nm

Media

SMF

Connector

TXPower

-7~2.3dBm

Extinction Ratio

>3.5dB

Receiver Sensitivity

<-13.7dBm

FIBERTOP 40G ER4 QSFP+ Transceiver SMF 1310nm 40km LC DOM

FIBERTOP QSFP+ ER4 transceivers are high performance, cost effective modules supporting data rate of 40Gbps and 40km transmission distance with SMF.

The transceiver consists of three sections: 4 inputs channels (ch) of 10Gb/s electrical data to 4 CWDM optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission;

on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and converts them to 4 channel output electrical data; and MCU control unit.

The transceivers are compatible with 40GBASE-ER4 of IEEE802.3ba standard and SFF-8436 specification.

Technical Specification

Vendor Name	FIBERTOP	FIBERTOP Part Number(s)	QFP-CW31FG-40DC
Transceiver Type	ER4	Reach	40km
Wavelength	1310nm CWDM4	Form Type	QSFP+
Speed Description	40Gb/s	Media	SMF
Connector	LC	Extinction Ratio	>5.5 dBm
TX Power	-2.7~4.5 dBm	Receiver Sensitivity	<-21 dbm
Applications	40GBASE-ER4 Ethernet Switch, router and HBAs Data Center Interconnect Infiniband QDR 40G Campus Link	Environment	Operating:0 to 70C Storage: -40°C to 85°C
